TRERICE D82LFB2502LA140 2.5" 0-300 LIQ FILLED PRESSURE GAUGE

This D80 Series liquid filled utility gauge by Trerice is designed for rugged performance applications at an economical cost. This liquid filled gauge is ideal to use in applications when vibration can occur. This gauge is furnished with a stainless steel case and crimped ring. The Wetted parts on this model are the bronze tube and brass socket. The case is 304 stainless steel, stem-mounted, and flangeless. The window is acrylic. The dial face is made of aluminum, with a white background with black graduations and markings.

Specs:
• Model D82LF of the D80 series
• 2-½” dial size
• ¼” NPT connection size
• Lower connection location
• Unit of measurement: psi
• 140 Range Code
• 0 to 300 psi
• 50 figure intervals
• 5 minor divisions
• Max temperature 150°F (65°C)
• ±1.6% full scale accuracy

EC Part Number: #51554
Mfg: Trerice
